Description

5.8G 40CH FPV Goggles 5 Inch 800*480 Video Headset EV800D HD DVR Diversity FPV Goggles With Battery For RC Model RC FPV Drone

Features

Low Power Consumption: The working current as low as 400mAh can greatly improve the battery life, so that you no longer have to worry about battery life.

Auto-Searching: Support a key search frequency to quickly and easily find the working frequency you need.

5 Inch HD Screen: 16:9 800*480 dot high brightness LCD HD Screen Provides better, clearer, and smoother picture quality.

Built-in Battery: Built-in 7.4V 1200mAh high-capacity rechargeable li-ion polymer battery. Each full charge can provide about 2 hr of working time when the DVR module is ON; and about 3 hr of working time when the DVR module is OFF.

Support Audio Signal Output: You can connect headphones.

Support External Video Signal Input.

Real-time video return, Very low time delay.

Specifications

Item Name: 800D Pro FPV Drone Goggle

LCD Screen: 5 inch 800*480 16:9 (Display Ratio)

Battery: 7.4V/1200mAh

Battery Charge: DC 12V/1A

Operating Current: [email protected] (Normal mode) ;[email protected] (Record mode)

Video Delay: video time delay less than 20 ms

AV Jack: External video signal input or internal Audio signal output

Card Slot: TF-Card Support up to 64G (C10 recommend)

Dimension: 180mm*140mm*84mm

Weight: 392g (w/headband,w/o receivers )

DVR

REC size: VGA /D1 /HD (selectable)

REC sound: ON /OFF (selectable)

REC time: OFF / 3min / 5min / 10min (selectable)

Frame rate: 30 Frames

Compress format: MJPEG

Record file format: AVI
